New parts for old bindings can be hard to find. Used parts for old bindings should now become easier. Trade in your used and/or broken Dynafit bindings for store credit, and we will make the working parts available for others. Please note that the photos shown here are often of new products, simply for reference. The item you receive may have visible wear. Used parts can be returned within 10 days if you are unhappy with the condition or discover the part will not work for you.
Please note these parts come with absolutely no warranty. We do a reasonable eyeball inspection of the parts, but can in no way guarantee their integrity. If you are not comfortable taking risks with used parts, please purchase a new part, toe, heel, or complete binding instead.
Check the drop list for the parts we currently have in stock. For parts with model names, the model should match your binding exactly. If a part works with more than one model, we use a generic descriptor with a reference chart below. Some specific notes:
B&D Classic Shim, 6.4mm - Drilled for ATK toe pieces.
B&D Speed Plates - Flat top plates for Dynafit binding heels which weigh just 20 grams per pair. Go without a high riser and save up to 60 grams (2.1 ounces) over stock Classic, Comfort, Vertical, or Speed Turn roofs.
Brake Retainer - Retainer "H" clip that holds Vertical, Comfort, and first-gen Radical brakes onto the heel piece.
Expedition Heel Pieces - Note, these are Non releasable bindings. includes mounting screws
Heel Adjustment Screw - Big lateral release screw cap for Radical 1.0, Speed Rad, Speed Turn. Often grey color.
Heel Thimble Bushing - Bushing that holds the lateral springs deep within Vertical, Radical 1.0, Speed Rad, and Speed Turn heel towers.
Radical 1.0 Crampon Receptors - The curved metal pieces that hold ski crampons onto Radical 1.0 toes.
Radical 1.0 Heel Pins - Pin with plastic spacer they pass through. Works with Radical 1.0 ,Speed Rad, and Speed Turn bindings.
Radical 1.0 Roof - Black top piece with risers for the Radical ST, FT and Speed Rad.
Radical 1.0 Roof Screws - The little Torx screws that hold the Radical 1.0 roofs on.
Radical ST Heel Complete - Heel piece like new. With screws.
Radical ST 1.0 Heel Turret - Includes the heel turret, heel adjustment screw, springs, and thimble bushing. Does not include the baseplate. Also compatible with the Radical FT.
Radical ST/FT 1.0 Toe Piece - Whole toe unit, but no baseplate or screws.
Radical ST/FT 1.0 Toe Plate - Plastic lifters under the Radical ST or FT (1.0) toe pieces.
Radical ST/FT 1.0 Heel Baseplate - Baseplates for the very first version of the Radical 1.0 that had removeable brakes (brakes not included). The newer version with the integrated brakes are listed as Radical ST/FT 1.0 brakes.
Radical Removable Brakes - Brakes for the first version of the Radical 1.0 bindings that required the "H" clip brake retainer. Retainer not included, listed as Brake Retainer above.
Speed Rad Heel Base - Adjustment mechanism w/ heel post. Often the older model with a brass pin for anti-rotation.
Speed Rad Heel Turret - A heel piece minus the base plate.
Superlite 2.0 Toe Piece, Green - Toe piece only with crampon connector and connector screws
Tristep Volcano - Can be used on Speed Turn, Radical or Vertical bindings.
Vertical ST/FT Toe Piece - Toe piece for the old ST or FT (as listed), w/out baseplate.
Vertical ST/FT Toe Plate - Plastic baseplate that goes underneath the toe pieces. Includes integrated metal crampon receptor.
Vertical ST/FT Heel Piece - Brakeless heel piece for the Vertical ST or FT (as listed), including base plate. These are sometimes white and sometimes brown. Brakes sold separately.
Vertical ST/FT Heel Turret - The whole turret that rotates on the base plate tower, complete with riser. No baseplate
Vertical Brake - Brakes that work with either Vertical model (ST or FT) and likely the Comfort series.
Greetings, I am looking for a Dynafit retaining clip for the bindings. I have a pair of the first generation Radicals and the clip that holds the binding in place next to the heel piece is missing. This is an H shaped clip, I have also heard someone call it the puzzle piece. Let me know if you have those and I will order a couple. Thanks, Matt 503-781-9646
Hi Matt, unfortunately we do not have any in stock and haven't seen any for some time. Keep an eye on the listing because if we get some we are sure to put them up on here!
Answer this question:
10/31/2018
Question from
Jared
I recently bought a pair of Dynafit Radical 2.0 ST bindings on clearance. Upon receiving one of the heel pieces was detached from the base plate. After further inspection, I noticed the square nut that sits in between the spring and the base plate on the actual heel piece was missing. Therefore I can't thread the long adjustment screw into the heel piece to reattach the baseplate to the heel piece. I was curious if you had that nut, or knew what diameter and thread count it is? Thank you fir your help.
Greetings, i contacted dynafit about a new pin/arm on my TLT ST Vertical 12 binding and they referred me to you. Is this a part you can replace? are there other parts from other bindings that i can drop in place that will work? As you can see in the pic the pin has sheared off from its home in the arm.
Dang Brady! Bummer! Unfortunately replacement wings are rarely a solution and you're looking at replacing the toe piece entirely. Looks like we're out of toes right now so if you're in a pinch, the Plum Guide or Race toes would drop into that hole pattern, as would the Kreuzspitze or even a number of other toe piece options. We can also set it up to alert you when we receive used toes in stock.
Answer this question:
6/10/2018
Question from
Matthew Madsen
Do you have or know where i could get two vertical toe plates? My old ones cracked and need some replacing. Thanks!
Hey Matthew! I don't have any vertical toe plates at the moment, so just by default the best way to get some new plates would be to get a new toe piece, unfortunately.
Hi Matthew, we did get some new Vertical toe plates in stock here.
Answer this question:
6/1/2018
Question from
Jason Luck
I have an older pair of the dynafit vertical 12 bindings and the heel piece no longer stays in the climbing position well when I'm sidehilling (after a few steps it rotates back to the no rise position). I put a friends older heels pieces on and it seemed to fix the problem, but I need to return those. I think this is pretty common problem with those bindings but am not sure what I need to repair the problem. Is it just a new spring and/or the white plastic cylinder that the spring pushes into the base plate post - or do I need a whole new heel piece or??? and of course do you have anything in stock that will fix the issue. Thanks for any help you can provide.
Hey Jason! There are a ton of factors at play here. Based on the picture, it looks like the entire heel piece, both baseplate and housing, came off your ski. Did you end up dropping their heel pieces into your ski, or did you just swap heel housings?Were your friends using brakes or were theirs brakeless as well? Did you use the same release value when your friends heel pieces were installed as your existing heel pieces were using? Feel free to send me an email and we can get to the bottom of it.
6/3/2018
Answer from
Jason L
Thanks for the response. I only put the picture up to show which binding I had - Nothing came off the ski until I took it off. I just swapped the heel pieces, which fixed the problem. I had (and still have) brakes on the skis. My friends heel piece only had a din of 10, so it was a slightly lower setting (I had mine maxed at 12).
Answer this question:
5/28/2018
Question from
Bob
Does the Vertical brakes 92mm include a brake retainer? I need to replace both on my bindings.
Hi,
I'm looking for Dynafit TLT Speed (2011) heel housing (without the base). Since there is no offer at the moment, I'm wondering if I could use Speed Radical Heel housing instead?
If not, I would buy the whole heel: does Radical ST Heel include the base?
Hey Casper! Unfortunately the tower diameter is going to make that really tough. The TLT Speed has a shorter tower that's smaller in diameter, whereas the newer Radical series bindings have a taller/thicker tower so I don't think it's going to work. That being said, the good news is that the hole pattern for most of Dynafit's heels hasn't changed in years so you could probably buy the complete Speed Radical heel here and drop it into the existing holes. Obviously, you'll want to consult our hole pattern article first before deciding this.
Answer this question:
4/11/2018
Question from
Kase Paul
Hi, I need part #3 for a Vertical FT binding. hard to tell what you guys call it. the plastic toe lock in mode and binding release...thingy cheers!
Hi Kase Paul, you are looking for the toe lever or "excenter" as Dynafit calls it. We do not have any in stock for the Vertical, but I have successfully repaired them in the past by using the toe lever from a Speed Radical or Radical ST/FT binding. You can find those in our Dynafit Parts Listing
Answer this question:
3/18/2018
Question from
Anita
I'm looking for a heel riser for a dynafit vertical st binding, photo attached. Thanks
Hi Anita, those are out of production. Your best bet is a B&D comfort plate + volcano.
Answer this question:
3/7/2018
Question from
Henrik
Hi,
I would need a pair of heel raisers (part 5), and one H-clip (part 9) for Verticals. Do you have any? The text is not visible anymore, so I don't know if the bindings are FT or ST.
Hi Tomek, that is not a part that Dynafit offers separately but we do have spring coupler sets from Maruelli.
Answer this question:
2/21/2018
Question from
chrisallan
I recently ordered a set of plastic heel cones for my old pair of Comfort bindings. Thanks. What are the specifications of the 8 bolts (image 5) which secure the heel pieces together, I need some replacements.
Looking for a compression spring and metal spacer pin from a radical 2.0 ski brake AFD. Spring is about 53mm long and 3.5mm outside diameter. The pin floats inside the coil. Please contact me if you can source these parts new or used. Thx
Hey Steven! Unfortunately I don't have any used AFD parts, though I do have an AFD kit here that includes the spring as well as an AFD, but no pin. If you have one to take a picture of would you mind sending it in? That may eliminate some confusion.
Answer this question:
1/16/2018
Question from
Jacob Lyman
Hey. So I crashed by truck and in the carnage, my brand new Radical 2.0 FT 120's broke- sorta. I am interesting in selling/trading/buying so I can get new pin tech bindings without buying new Dynafits, cause I am in school and broke, so if you have any ideas, and I mean ANY ideas, lemme know. Here is the situation with the bindings.
Both toes pieces are 10/10 not damaged, used twice and not even a paint chip to remember the turns. One heel piece is the same way, in perfect conditions and looking gucci. The other heel piece is where the sad part lies. I don't know the names of all the parts, so bear with me here. The grey track that mounts to the ski? Yeah, the black rotating heel piece that can be adjusted via the rear screw popped outa the track, and I am missing a small tab of plastic on the bottom rear of that same heel piece. This plastic tab holds the black bolt which is screwed midway onto the silver screw underneath the black rotating heel piece. This black screw presses against the plastic tab I am missing, providing a place for the silver spring which is set around the silver screw underneath the black heel piece to push back on. I am also missing this spring, and I suspect I am missing a piece which the end of the silver screw screws into, which I further suspect to provide the other end of the spring a place to press against.
Thank you for reading this novel, and if you have ANY help at all please let me know.
Jacob, From the sound of it the damage is only to the baseplate and not the actual heel piece. You can potentially get a new Dynafit Radical 2.0 baseplate/brake in a 120mm width, remount it and place the old heel piece on the new plate. Otherwise, it definitely gets more complicated to fix.
Hi Jacob, I concur with I-M that you need a new baseplate+brake! It's possible you need a new housing as well, but I don't see any specific damage to that in the photo.
So this bit broke off, circled. Am I using the wrong name? The grey track at the bottom of the binding is what I am calling the baseplate- am I wrong???
Hi Nick, while we are no longer able to get Vertical toe levers, Dynafit recommends the Speed Radical toe levers as replacements. You can find those levers in our Dynafit Binding Parts listing.
Answer this question:
12/11/2017
Question from
Mirek
Hi I have Dynafit TLT Vertical ST bingings. Unfortunatly one heel stand(handler) was broken (see attached foto). Do You have this spart part in stock? (I think that this is part number 4 on picture above).
Mirek- You have to replace the whole heel housing to replace that tab. Unfortunately we do not have any at the moment. We get people trading in bindings and we then list the usable parts here. The heel should still function unless you want to use a brake in which case the tab is necessary.
